Q-MAX 150
Displacement
149.6 CC
Max Speed
90 Km/h
Max Power (Kw)
8 kw
Max Torque
12 N.m
Q-MAX 150
| Engine | |
| Displacement | 149.6CC |
| Engine Type | Single Cylinder,4-Stroke,Air-cooled |
| Start | ELECTRIC/KICK |
| Ignition | C.D.I |
| Compression Ratio | 9.2:1 |
| Transmission | Belt Drive |
| Max Power (Kw) | 8 KW |
| Max Torque | 12 N.m |
| Chassis,Dimensions and Weight | |
| Dimension：L×W×H (mm) | 1970×780×1160mm |
| Weight(Kg) | 128 KG |
| Wheel Base(mm) | 1380mm |
| Seat Hight(mm) | 765mm |
| Min Ground Clearance(mm) | 130mm |
| Wheels,Suspension and Brakes, others | |
| Brake Modes | Fr. Disc / Rr. Drum |
| Tire Size | Fr.100 / 80-14;Rr.120 / 70-14 |
| Max Speed | 90 Km/h |
| Capacity of Fuel Tank (L) | 5.5L |
| Lights | LED |
